Pharmaceutical 2GPM OEM EDI Purified Water System

Name: Pharmaceutical 2GPM OEM EDI Purified Water System
Brand: Fenigal/OEM
Price: 1 USD

Quality Pharmaceutical 2GPM OEM EDI Purified Water System wholesale

Brand Name : Fenigal/OEM

Model Number : IX-3A-1

Certification : CE/NSF etc.

Place of Origin : China

MOQ : 1 Set

Price : Negotiable

Payment Terms : T/T, Western Union, Paypal etc.

Supply Ability : 200 set per month

Delivery Time : 15~30 days

Packaging Details : Standard Export Wood Crate/Carton or Naked wrapped by film/Containerized

Technology : Pressurized filtration

Material : carbon steel/FRP/stainless steel

Design : Skid mount/containerized

Water temp. : 5~35˚C

Water flow rate : Up to 200 m3/day.vessel

Voltage : 380V,415V,220V,can be customized

Application : Surface, underground water, sewage water treatment

Size : Dia.20cm~180cm

Control : electronic,Manual/PLC

Contact Now

Electro-deionization ultrapure water demineralizer system for pharmaceutical, power, microelectronic industries

Electrodeionization (EDI) Systems remove ions from aqueous streams, typically in conjunction with reverse osmosis (RO) and other purification devices. Our high-quality modules continually produce ultra-pure water up to 18.2MΩ/cm. EDI may be run continuously or intermittently. Electrodeionization is a green solution for deionizing water. With no expensive chemical upkeep and virtually no down-time, electrodeionization units are the future in deionization.

Electrodeionization Equipment Advantage:

The need to satisfy the increasing demand for high purity water can be achieved using Electro-Deionization (EDI) equipment. The EDI process replaces conventional DI mixed resin beds to produce deionized water.

EDI modules are on average miniature in size and weight in terms of per unit flow in the market. Unlike DI resin, EDI water purification systems do not require shutdowns for replacing resin beds or for resin regeneration using chemicals. As a result the EDI minimizes water quality upsets and operating costs.

EDI has become the solution of choice, lower operating expenses and fewer maintenance requirements makes EDI the cost effective choice over mixed bed IX or dual-bed polishing. Fewer maintenance demands also means less facility needs and managerial supervision, which saves additional labor costs.

These systems also require minimal energy to provide steady, and persistent ultra pure water. EDI water purification systems utilize compact footprints, which benefits water treatment plants in using less available space to provide the same amount of water.

Spec.----

Model No.	Flow Rates (GPM)			Voltage (DC)		Current (Amps)
	Product			Typical Operation	Maximum	Typ. (4ppm RO Feed)	Max. (15ppm RO Feed)
	Avgerage	Peak	Concentrate	Typical Operation	Maximum	Typ. (4ppm RO Feed)	Max. (15ppm RO Feed)
EDI-2	2.00	3.00	0.20
EDI-5	5.00	7.50	0.50
EDI-9	9.00	13.50	0.90		300	2	6
EDI-12	12.50	18.80	1.25
EDI-15	15.00	22.50	1.50
EDI-22	22.50	33.80	2.25	250-300
EDI-27	27.50	41.25	2.75		470	2	7
EDI-55	55.00	82.50	5.50		600	2	7
EDI-82	82.50	123.75	8.25		470	4	14
EDI-110	110.00	165.00	11.00		600	4	14
EDI-165	165.00	247.50	16.50		600	6	21
EDI-220	220.00	330.00	22.00		600	8	28

FEED WATER SPECIFICATIONS

Feed Water Conductivity Equivalent, including CO2
and Silica: < 40 µS/cm
Feed Water Source: RO permeate
Temperature: 41 – 113 °F (5 – 45 °C)
Inlet Pressure: = 100 psi (6.9 bar)
Maximum Total Chlorine (as Cl): < 0.02 ppm
Iron (as Fe): < 0.01 ppm
Manganese (as Mn): < 0.01 ppm
Sulfide (S2-): < 0.01 ppm
pH: 4 – 11
Total Hardness (as CaCO3): < 1.0 ppm
Dissolved Organics (TOC as C): < 0.5 ppm
Silica (SiO2): < 1.0 ppm

Features:

Benefits of EDI:

Small, compact modules (light weight)
Produces water up to 18 MΩ-cm
Easy and limited maintenance
No chemicals required
Control unit with monitoring capability
Simple systems: no concentrate recirculation

Consistent water quality
Continuous operation
No regeneration chemicals
No hazardous waste
Reduces facility requirements
Simpler system—no concentrate recirculation
Simple operation (no batch DI resin changes)
Modular system more flexible, easy to expand
Multiple module less risky than one large stack
Dial in product water quality (by controlling Amps)
Modules compact-smaller system footprint
No leaking- proven module design>
Safer-lower voltages

The ideal applications for an Electro-Deionization Unit include:
USP Purified Water Laboratory Water	Power Generation Cosmetics	Portable Exchange EDI Electronics
