DOW FilmTec™ LC LE PRO-4040 Water Treatment With Barcol Hardness Test Every 1.5 Meters At 25C Reverse Osmosis Membranes

Key Features

The DOW FilmTec™ LC LE PRO-4040 Reverse Osmosis Membranes deliver high-quality water at low pressure, even under harsh water conditions. These membranes utilize DuPont's innovative, proprietary technology for low-energy applications, offering significant benefits in both efficiency and performance:

• Industry-Leading Active Area (94 sqft): Ensures reduced fouling due to lower operating flux while still achieving higher flow rates.

• High Salt Rejection: Operates at low pressures in harsh water conditions, offering exceptional salt rejection.

• Effective Cleaning Performance: Features the widest cleaning pH range (1-13) and outstanding chemical tolerance, ensuring durability and reliability.

Key Applications

The LC LE PRO-4040 Reverse Osmosis Membranes are ideal for various light industrial applications, particularly those requiring high-quality permeate water. Typical uses include:

• Harsh Feed Water Conditions

• Drinking Water: Suitable for refilling stations, bottling plants, hotels, schools, and institutions.

Typical Properties

• Test Conditions: 2000 ppm NaCl, 77°F (25°C), 15% recovery, pH 8, applied pressure 150 psig. Individual permeate flows may vary +/- 20%.

Operating and Cleaning Limits

The LC LE PRO-4040 Reverse Osmosis Membranes have the following operating and cleaning parameters:

Note: Maximum temperature for continuous operation above pH 10 is 95°F (35°C). Refer to FilmTec™ Cleaning Guidelines for specific cleaning instructions.

General Information

To ensure the longevity and performance of the DOW FilmTec™ LC LE PRO-4040 Reverse Osmosis Membranes, please follow these operational guidelines:

• Keep elements moist at all times after initial wetting.

• For successful operation of Reverse Osmosis (RO) and Nanofiltration (NF) membrane systems, refer to FilmTec™ Reverse Osmosis / Nanofiltration Elements Operation Excellence and Limiting Conditions Tech Fact.

• To prevent biological growth during system shutdowns, immerse membrane elements in a preservative solution.

• Maximum pressure drop across an entire pressure vessel (housing) is 50 psi (3.4 bar).

• Avoid static permeate-side backpressure and discard permeate obtained from the first hour of operation.

Important Information

Proper start-up of the Reverse Osmosis Membranes is crucial for optimal performance. Follow the recommended procedures to prevent damage from overfeeding or hydraulic shock. The FilmTec™ Reverse Osmosis Membranes Technical Manual provides detailed guidance.

• System Start-Up: Ensure all system checks are completed before initiating start-up, including membrane pretreatment and instrument calibration.

Regulatory Note

This product may be subject to drinking water application restrictions in some countries. Please verify application status before use and sale.
